    Highly Efficient Hydraulic Breaker Continuously Operate SPA8 Pile Breaker Environmental Machine

    Ask Lasest Price
    Brand Name : SINOVO
    Model Number : SPA8
    Certification : CE
    Payment Terms : T/T, L/C
    Delivery Time : STOCK
    Price : Negotiable
    Supply Ability : 30 sets per month
    • Product Details
    • Company Profile

    Highly Efficient Hydraulic Breaker Continuously Operate SPA8 Pile Breaker Environmental Machine

    Benefits of the SPA8 pile breaker:


    1. Highly efficient - it can operate continuously.

    2. Low noise levels - the hydraulic pressure drive does not cause disturbances

    3. Long life - the main unit is made from specical material using superior technology.


    The work environment:


    1. Because of the project machinery and pile basis may have something no indeterminacy,so break the pile depth at most 300mm at every turn.

    2. Choose the hydraulic pressure oil tube and joint on the basis of the motive power's source oil tube before assembly.Check the hydraulic pressure oil tube is connected, then test press. Hold for one minute to check whether there is any leakage. If not, proceed with using the unit.


    SPA8 Hydraulic pile breaker which can break square pile (1450-1600mm) with 11pcs of moduel.
    1.Max drill rod pressure: 790kN
    2.Max cylinder stroke: 230mm
    3.Max cylinder pressure: 31.5MPa
    4.Max sigle cylinder flow: 25L/min
    5.Quanity/8h: 30-100 pcs/8h
    6.Single cut pile height≦300mm
    7.One-piece moudule weight: 410kgs
    8.One-piece moudule size: 938x840x450mm
    9.Work status dimensions wih 13pcs of moduel: 3700x450mm
    10.Total weight: 5.5t
    Module numbersThe diameter range (mm)Platform weight(t)Total pile breaker weight(kg)Height of single crush pile(mm)
    6450-650202460300
    7600-850222870300
    8800-1050263280300
    91000-1250273690300
    101200-1450304100300
    111400-165032.54510300
    121600-1850354920300
    131800-2000365330300
