    SPA5 Hydranulic Concrete Breaker For Cutting Piles Cut 120 Piles/8h Break Round Pile, Pile Cutter

    320KN Hydranulic Concrete BreakerFor Cutting Piles 8h Cut 120 Piles


    SPA5 Hydraulic pile breaker which can break square pile (400-500mm) with 4pcs of moduel.
    1.Max drill rod pressure: 485kN
    2.Max cylinder stroke: 150mm
    3.Max cylinder pressure: 31.5MPa
    4.Max sigle cylinder flow: 25L/min
    5.Quanity/8h: 60 pcs/8h
    6.Single cut pile height≦300mm
    7.One-piece moudule weight: 210kgs
    8.One-piece moudule size: 895x715x400mm
    9.Total weight: 2.5t


    The cylinder is installed from the structural part’s top to its end. The force goes to the whole structural parts, protect the bolt from breaking off.

    The alloy bit and cylinder are connected in the middle of the alloy bit. Uniformly forced, the machine won’t be damaged during working. The material of our alloy bit is military use alloy steel, with higher strength and longer using life, it can cut 5000 nos. of piles.

    Chain: Professional hoisting chain with single lifting capacity of 5t, diameter 14mm,offering high safety guarantee. Equipped with adjusting buckles, the chain’s length could be adjusted according to jobsite condition easily

    Structural parts—Both the material and techniques are more matured, with high standard quality control and long service life.

    The two pins are used for fixing the modules and have the limit role, which is not only instead of top metal ring frame to reduce weight of the whole machine, but also avoid the pile colliding the top metal ring frame during the pile breaking.


    ModelSPA5
    Range of Pile diameter (mm)Ф1050-Ф1200
    Maximum Drill rod pressure485kN
    Maximum stroke of hydraulic cylinder150mm
    Maximum pressure of hydraulic cylinder31.5MPa
    Maximum flow of single cylinder25L/min
    Cut the number of pile/8h60
    Height for cutting pile each time≦ 300mm
    Supporting the digging machine Tonnage (excavator)

    ≧ 20t


    One-piece module weight210kg
    One-piece module size895x 715 x 400mm
    Work status dimensionsФ2670x 400
    Total pile breaker weight2.5t


    As a long-established drilling rig manufacturer in China, we Beijing SINOVO International Company(SINOVO Heavy Industry Co., Ltd ) do business with reputation and word of mouth. We are dedicated to provide customers perfect service. To make customers feel secure in using our products, we establish a complete after-sales service system, and provide a one-year warranty for our drilling rigs. During the warranty period, we provide free debugging, operator training and maintenance service. In addition, we also offer free spare parts. As our main components are imported from world renowned companies, our overseas customers can maintain these components easily.
