    57.5m Depth TR158 Rotary Drilling Rigs Hydraulic Telescopic Crawler for construction work

    TR158 Hydraulic Telescopic Crawler Rotary Borehole Drilling Rig 57.5m Depth


    The TR158 rotary drilling rig has a maximum output torque of 158KN-M, a maximum drilling diameter of 1500mm and a maximum drilling depth of 57.5m. It can be widely used in municipal, highway, railway bridges, large buildings, high-rise buildings and other construction fields, and can achieve efficientdrilling of hard rock.


    TR158 Main Technical Specification:


    Pile

    Parameter

    Unit

    Max. drilling diameter

    1500

    mm

    Max. drilling depth

    57.5

    m

    Rotary drive

    Max. output torque

    158

    kN-m

    Rotary speed

    6~32

    rpm

    Crowd system

    Max. crowd force

    150

    kN

    Max. pulling force

    160

    kN

    stroke of crowd system

    4000

    mm

    Main winch

    Lifting force (the first layer)

    165

    kN

    wire-rope diameter

    28

    mm

    Lifting speed

    75

    rm/min

    Auxiliary winch

    Lifting force (the first layer)

    50

    kN

    Wire-rope diameter

    16

    mm

    Mast inclination angle

    Left/right

    4

    °

    Forward

    4

    °

    Chassis

    Chassis model

    CAT323


    Engine manufacturer

    CAT

    CATERPILLAR

    Engine model

    C-7,1


    Engine power

    118

    kw

    Engine speed

    1650

    rpm

    chassis overall length

    4920

    mm

    Track shoe width

    800

    mm

    Tractive force

    380

    kN

    Overall machine

    working width

    4300

    mm

    working height

    19215

    mm

    Transport length

    13923

    mm

    Transport width

    3000

    mm

    Transport height

    3447

    mm

    Total weight(with kelly bar)

    53.5

    t

    Total weight(without kelly bar)

    47

    t


    Feature and advantages of TR158 rotary drilling rig:


    1. The latest version of the system optimizes some of the drilling assistance operations, making the operation smarter and easier than before. This upgrade can further reduce maintenance costs by 20%: extended maintenance cycle, reduced hydraulic oil consumption; elimination of pilohydraulic oil filter; Replace the shell drain filter with a magnetic filter; the new air filter has a stronger ability to accommodate dust; Fuel and oilfilters are "in one room"; superior part versatility reduces customer maintenance costs;
    2. The TR158H rotary drilling rig adopts the new CAT electronic control chassis, and the upper frame is reinforced, which makes the working reliability of the wholemachine significantly improved;
    3. The TR158H rotary drilling rig whole machine adopts the electronic control system control, the sensitivity of the components is improved,and the work efficiency is improved;
    4. The pilot pump and the fan pump are eliminate (using the electronic fan pump) increases the net power of the hydraulic system;
    5. The power head of TR158H rotary drilling rig increases the guiding length of the drill pipe, prolongs the service life of the power head, and improves theaccuracy of the hole forming;
    6. The power head of TR158H rotary drilling rig adopts a flip-chip gear box to reduce the maintenance cost.

    Q: Are you a trading company or a manufacturer?

    A: We are a professional manufacturer, and our factory mainly produces series hydraulic rotary rig, hydraulic pile breaker, exploration equipment, core drilling rig and related piling equipment etc.


    Q: What kind of product certification do you have?

    A: Our series products have passed ISO9001, Gost and CE certifications.

    We strictly perform quality inspection process before shipment and supply the best quality machines to our customers.


    Q: Do you have after sales service?

    A: Yes, we have professional service team to assist our clients . If you request, we can dispatch our engineer to your worksite to provide training for your staff. For the chassis, eg CAT chassis, our clients can enjoy global after service support.


    Q: How about the warranty policy ?

    A: Most of our products support 1 year or 2000 working hours warranty, please consult customer service for specific products


    Q: Do you test all your goods before delivery?

    A: Yes, we have strict quality inspection process before shipment, and the clients also authorize SGS to inspect our machine.
