    1800mm Slurry Balance Pipe Jacking Machine For Tunnel Construction

    Ask Lasest Price
    Brand Name : SINOVO
    Model Number : NPD1800
    Certification : CE/GOST/IS9001
    Price : Negotiation
    Supply Ability : 30 unit per month
    Delivery Time : 7-10 work days
    • Product Details
    • Company Profile

    1800mm Slurry Balance Pipe Jacking Machine For Tunnel Construction

    1800mm Slurry Balance Pipe Jacking Machine For Tunnel Construction


    Device positioning:


    Safe Tunneling Technology in Heterogeneous Ground


    Geological condition:


    Soft soils, heterogeneous formations (sand, gravel, high permeability and high water pressure)


    The NPD series pipe jacking machine is mainly suitable for the geological conditions with high groundwater pressure and high soil permeability coefficient. The excavated slag is pumped out of the tunnel in the form of mud through the mud pump, so it has the characteristics of high working efficiency and clean working environment.


    Main Technical Specification:


    Diameter (mm)Dimensions D×L (mm)Weight (t)Cutter diskSteering Cylinder (kN × set)Internal pipe (mm)
    Power (kW×set)Torque (Kn·m)rpm

    Φ800

    1020×3400

    5

    75×2

    48

    4.5

    260×4

    50

    Φ1000

    1220×3600

    6.5

    15×2

    100

    3.0

    420×4

    50

    Φ1200

    1460×4000

    8

    15×2

    100

    3.0

    420×4

    50

    Φ1350

    1660×4000

    10

    22×2

    150

    2.8

    600×4

    50

    Φ1500

    1820×4000

    14

    30×2

    150

    2.8

    800×4

    70

    Φ1650

    2000×4200

    16

    30×2

    250

    2.35

    800×4

    70

    Φ1800

    2180×4200

    24

    30×3

    300

    2

    1000×4

    70


    Feature and advantages of NPD1800 slurry balance pipe jacking machine​:


    1. The NPD series pipe jacking machine adopt reliable main bearing, main drive seal and main drive reducer, with long service life and high safety factor.

    2. Self-developed control software system, the performance of the whole machine is safe and reliable, and the operation is convenient.

    3. Wide applicable various soil, such as soft soil, clay, sand, gravel soil, hard soil, backfill, etc.

    4. Independent water injection, discharge system.

    5. The fastest speed is nearly 200mm per minute.

    6. The construction of high precision, steering maybe the up, down, left and right, and the most steering angle of 5.5 degrees.

    7. Use the central control system on the ground, safe, intuitive, and convenient.

    8. A series of tailor-made solutions can be provided for different project requirements.
