    Portable Hydraulic 1500m Deep Truck Mounted Drill Rig Water Well Drilling Rig

    Ask Lasest Price
    Brand Name : SINOVO
    Model Number : SNR1000CS
    Certification : CE/GOST/ISO9001
    Price : Negotiation
    Payment Terms : L/C, D/A, D/P, T/T
    Supply Ability : 30 pers month
    Delivery Time : 7-10 days
    • Product Details
    • Company Profile

    Portable Hydraulic 1500m Deep Truck Mounted Drill Rig Water Well Drilling Rig


    Portable Hydraulic Trailer Truck 1500m Deep Water Well Drilling Machine


    SNR1000CS full hydraulic double rotary head water well drilling rig, It can be drilled with DTH hammer, and can also be drilled with mud pump , casing rotator to meet different geological conditions. It is suitable for large diameter water wells, pile holes, mining rescue and other projects.
    The rig can provide three different types of drilling rig, such as truck, trailer type and crawler type, according to the needs of the users.
    The drilling rig is powered by two diesel engines. The upper rotary power head is made up of high-speed motor and gearbox, and the bottom rotary head is made up of low speed, high torque hydraulic motor and gearbox. The propulsion system is fed by the oil cylinder. Rotating and feeding system are controlled by hydraulic pilot control which can achieve stepless speed regulation. Breaking out and in drill rod, leveling the whole machine, winch and other auxiliary actions are controlled by hydraulic system.


    Technical Parameters


    Drill modelSNR1000CS
    Diesel engineModel Cummins6LTA8.9-C325
    KWPower239
    rpmRotate speed2200
    Rotary headrpmRotate speed0-150
    N.mMax. torque32000
    KNMax. pullback force500
    KNMax. feed force500
    MastmHeight14.5
    Angle0︒-90︒
    mStroke10.5
    RodmmDiameter89/114/127/159
    RC (reverse circulation) drillingmmMax. diameter1500
    mDepth200
    Rock with water and air composite DTHmmMax. diameter600
    mDepth600
    m³/KgAir consumption31/24
    New DTHmmMax. diameter300
    mDepth1500(1000)
    m³/KgAir consumption31/24
    Traditional DTHmmMax. diameter300
    mDepth120
    m³/KgAir consumption31/24
    RC pumpModel6,7
    Mud pumpModelBW1200/14
    WinchKNLifting force15+50+100
    Transport dimensionKgWeight25000
    LxWxH mmOverall dimensions14500x2650x3800

    Optional
    Rig operation by truck or trailer or crawlerMast extensionBreakout cylinderAir compressor
    Centrifugal pumpMud pumpWater pumpFoam pump
    RC pumpScrew pumpDrill pipe boxPipe loader arm
    Opening clampSupport jack extension

    FAQ


    1. About Price: The price is negotiable. It can be changed according to your quantity When you are making an inquiry, please let us know the quantity you want.

    2. About MOQ: If the drilling rigs, the MOQ is 1 set; If the drilling tools ( DTH hammers & bits ) , the MOQ is 10 pcs;

    3. About OEM and ODM: Welcome, you can send your own design of product and LOGO to our company.


    Packaging & Delivery

    Selling Units:
    Single item
    Single package size:
    514500x2650x3800 mm
    Single gross weight:
    25000 kg
    Package Type:
    Portable Hydraulic Trailer Truck 1500m Deep Water Well Drilling Machine
    Lead Time :
    Quantity(Sets)1 - 1>1
    Est. Time(days)7To be negotiated
